About Ace Anodizing & Impregnating, Inc.

About Ace Anodizing

For over 60 years Ace Anodizing and Impregnating has been your trusted source for Type II, Type III Hardcoat, Bright Dip Anodizing and Two Step Architectural Anodizing. With a full service powder coating operation, a large capacity die cast impregnation line, chromate conversion capabilities and two state of the art Anodizing lines, Ace can meet all of your chemical finishing needs under one roof. In addition, we have a full-service, value-added Precision Cut Back sawing department to minimize handling and help manage inventory challenges.

Conveniently located in Hillside Illinois, we are easy to get to and offer quick turns at a competitive value. Our Quality System is ISO 9001:2015 Certified and we are committed to exceeding your expectations. We offer trucking services (call for details). We can also process long parts up to 282” long depending on the process.

We are pleased to offer the following services:

Anodizing Services

  • Anodize to MIL-PRF-8625
  • Type II Anodizing Clear and Colors
  • Type III Hard Coat Anodizing Clear and Colors
  • Architectural Two Step Anodizing, Clear, Champagne, Light/Med/Dark Bronze, Black
  • Bright Dip Anodizing Clear and Colors
  • Stock and Custom Colors
  • Electrolytic and Immersion Coloring Processes
  • Chromate Conversion – Clear and Yellow. ROHS Compliant Large parts up to 24′
  • Two Lines:
    • Line one maximum part size 150″ x 24″W x 48″D
    • Line two maximum part size 282″ x 38″W x 60″D

Vacuum Impregnation Services

  • All ferrous and non ferrous metals including zinc and aluminum die castings
  • Large Capacity Processing Line
  • Wet Vacuum and Pressure Impregnation/Thermal Curing Process
  • Mil-I7563C
  • Mil-STD-276A
  • UV Inspection and coverage testing
  • Certified to Worldwide Automotive Standards, commercial specifications and OEM approvals.

Powder Coating Services

  • Powder Coating of large parts. Maximum part dimensions 25’L x 10’W x 8’H
  • Iron Phosphate and Chromate Conversion Pre-Treatment
  • Stock and Custom Colors Epoxy, Polyester, Hybrid, Urethane, Poly Acrylic
  • Architectural Powder application capabilities
  • AAMA 2603, AAMA 2604 and AAMA 2605 Certified.

Precision Cutback Sawing Services

  • Capable of cutting bars or extruded profiles/shape.
  • Cut Height: 8”
  • Maximum Width: 24”
  • Minimum length: .5”
  • Maximum Length: 25’
  • Saw Carriage Speed: up to 500 IPM
  • Gauge Speed: Up to 1000 IPM
  • Straightness of Cut:+/-.005” over full range
  • Parallelism: +/-.003/ft
  • Horizontal Squareness: +/-.002 in/ft corner to corner
  • Vertical Squareness: +/-.001in/in of thickness

For over 60 years companies have been making Ace Anodizing and Impregnating, Inc. there number one choice for their metal finishing needs. For more information contact us @ mike@acemetalfinishing.com.
